1905 X 1270MM CCL Press Cushion Pad Copper Clad Lamination Pad

CCL Press Cushion Pad For Copper Clad Laminate Lamination ESCP-CCL-G1

1. Introduction of CCL Press Cushion Pad For Copper Clad Laminate Lamination ESCP-CCL-G1

CCL cushion pad is the red rigid cushion pad which can well replace hot press kraft paper and improve dimensional safety and stability (industry standard tolerance:+/-300ppm/it can reach+/-250ppm after using such CCL cushion pad). It has excellent lamination comprehensive performance and high stability, which can greatly improve the yield and efficiency in the process of CCL (copper clad laminate) production process.

CCL cushion pad is also named or known as CCL lamination cushion pad, CCL cushion mat, CCL buffering pad or CCL hot press cushion pad. It is the necessary and important cushion and buffering materials to finish the CCL (copper clad laminate) lamination process.

CCL cushion pad (press pad/cushion mat/buffering pad/hot press cushion) for CCL (copper clad laminate) lamination purpose is suitable for physical buffering operations in the middle layer and manual operations for multiple sheet replacements. It is also suitable for automated CCL laminating operations and can replace multiple sheets of hot press kraft paper with one single pad.

2. Product feacture of CCL Press Cushion Pad For Copper Clad Laminate Lamination ESCP-CCL-G1

The product advantages of CCL cushion pad (lamination press pad/cushion mat/buffering pad/hot press cushion for CCL (copper clad laminate) lamination purpose) are summarized as below:

1). It can be repeatedly pressed for 600-800 times, which can significantly reduce the production cost of CCL (copper clad laminate).

2).It performs well in terms of cushion pad flatness, wear resistance, size increase ratio, thickness variation, which is far superior to hot press kraft paper in the process of CCL lamination.

3). It features better performance in high temperature resistance, able to work for a long time at no more than 280℃ without carbonization or brittleness.

4). It features excellent buffering effect and thermal conductivity, stable compression increase and expansion coefficient, and good tear resistance.

5). It is flame retardant, non-toxic and odorless, dust-free and shavings free with good breathability.

6). We can give you the shorter delivery time with more competitive prices and quality control.

3. Product structure of CCL Press Cushion Pad For Copper Clad Laminate Lamination ESCP-CCL-G1

 Nano high temperature resistant coating

 Fiberglass cloth

 High molecular weight polymer

 Tensile tear layer

 Polymer aggregates

 Fiberglass cloth

 Nano high temperature resistant coating

4. Technical parameter of CCL Press Cushion Pad For Copper Clad Laminate Lamination ESCP-CCL-G1

1). Service life: 600-800 times.

2). High temperature resistance performance: ≤280℃

3). Thickness: 4mm-6.5mm.

4). Thickness tolerance: ±0.3mm.

5). Normal regular Sizes (L*W in mm): 2220*1270/2120*1270/1920*1270/1905*1270/1270*1070/1270*1120/1270*800

6). Size tolerance (length or width): ±2mm.

7). Tensile strength ≥ 25 MPa

8). Buffer standard: ≥ 12%

9). Water absorption standard :< 8% (3-8%)
